Further indications are given in the pages to follow and in the user instructions.
Water supply indicator
Check the appliance fills with water.
Lower spray arm block indicator
Release the spray arm.
“Water stop” device indicator
“Water stop” device not working.
Switch off the dishwasher and shut off the water
tap.
Rinse aid level indicator
Add rinse aid.
Salt level indicator
Add regeneration salt; only add regeneration salt
immediately before starting a wash programme.
Programme progress indicator Delayed start buttons
The wash cycle can be programmed to start after 1-24 hours. Then
press the Start button.
The dishwasher will start at the set time.
Time and failure display
Indicates in hours the time remaining until the start of the wash cycle.
Switches off when the programme has started. Toward the end of the
programme, during the drying cycle, the display will indicate the time
remaining in minutes.
“F1-F9” Identification of faults for the service technician.
Start button
Indicator lamp lit while the dishwasher is operating. Flashes when a
fault occurs.
Switches off at the end of the programme.
On / Off Button
Pre-rinse /
Pre-wash
Washing
Drying
Programme
end
Options
Eco-Dry
The indicator lamp switches on during dry
cycles without fans.
Programme Symbol
and Temperature
Programme selection and
recommended load type
Place the detergent in the:
small compartment large compartment Consumption 1)
Normal load
Water
(Litres)
Energy
(kWh)
Time
(Min.)
Eco Normal 40 - 55° C Recommended programme
for routine washes, for
crockery with little or no dried-on food. X X
Intensive 60 - 70° C
Recommended programme for heavily soiled crockery
,
with dried-on food. Especially suitable for pans and
saucepans.
X X
Pre-wash Crockery to be washed later. - - 95.0 0.02
Rapid 40° C Lightly soiled crockery with no dried-on food. - X 13.0 0.85 30
Glasses 40° C Light soiling, especially glasses and cups. - X 12.0 0.82 60
Standard 50° C 2) Normally or heavily soiled crockery with dried-on food. X X 16.0 1.05 120
DYNAMIC SENSE: Energy savings and optimum wash results
The two sensor-controlled “ DYNAMIC SENSE” wash options are
recommended for routine washes. They use double-sensor
technology. Separate sensors gauge turbidity and particles in order
to determine the degree of soiling of the wash water. In accordance
with values measured, a microprocessor establishes optimum water,
energy and time consumption. Optimum wash results are thus
achieved using only those resources strictly required.
Quick Reference Guide
GB
5019 100 90235
(We reserve the right to make technical modifications)
1) Values may vary in relation to usage, e.g.: different loads, water temperatures - above or below 15° C -
as well as water hardness and power supply voltage.
2) Reference programme for Test Institute and energy-label.
GSF 7499
