5019 496 90441
GB
Quick Reference Guide
Before using the dishwasher, read the user instructions!
BK/I/B/GB
(We reserve the right to make technical modifications)
GSFH
Symphony 05
Add regeneration salt
Only add regeneration salt immediately before
starting a wash programme.
Add rinse aid
Time and failure display3)
Indicates in hours the time remaining until the start of
the wash cycle. Switches off at programme start and
indicates the remaining time in hours and minutes.
“F....” Information for the After-Sales Service
“Delayed start” button
The wash cycle can be programmed to start after
1 - 24 hours. With each successive touch of the
button, the delayed start indicator increases by 1
hour, and after 24 returns to 00. Then press the Start
button. The dishwasher will start at the set time.
“Half load - Multizone” button
Load the upper or lower rack only.
This function can be used with any programme.
Press once = upper rack (the indication lamp/
symbol comes on)
Press twice = lower rack (the indication lamp/
symbol comes on)
Press 3 times = Off (half load function deactivated).
When washing without the top rack, press the “Half
Load” button twice, or “Lower rack wash” (the
corresponding LED/symbol comes on).
Antibacterial rinse 4)
This function adds an antibacterial rinse at the end of
the wash cycle, thereby guaranteeing a perfectly
clean and sanitized load. The lamp will light up when
the function is activated. If the temperature is not
maintained during the antibacterial cycle (e.g. if the
door is opened and remains open for a long time),
the lamp will start blinking to indicate that sanitation
is not guaranteed.
1) Reference programme for energy label EN 50242
(Liter = 13.0, kWh = 1.05, Min. = 170);
2) Refer to “User instructions”;
3) Programme data obtained in conformity with European
standard EN 50242. Values may vary in relation to usage, e.g.:
different loads, water temperatures - above or below 15°C - as
well as water hardness and power supply voltage, etc.
4) The bacteria removal efficiency has been tested by the
Institut Pasteur de Lille (France), based on the NF EN
13697 standard of November 2001.
5) These programmes can be used with the Antibacterial
rinse option.
Programme selection button
On / Off button
Start button
Switches “on” when the dishwasher is operating.
Flashes when a fault occurs. Switches off at the
end of the programme.
Indicators
Options
Programme chart Detergent 2) Consumption 3)
Programmes Loading instructions A B Litres kWh Minutes
Sensor + 1) 5) 40-70°C Lightly, normally or heavily soiled
crockery, including pots and
pans.
X X 7.0-17.0 0.99-1.58 65-170
Pre-Rinse cold Crockery to be washed later. - - 4.0 0.03 14
Glass 40°C Light soiling, for example glasses
and cups. X - 10.0 0.80 55
Rapid 30 min 40°C Lightly soiled crockery with no
dried-on food. X - 10.0 0.65 30
Important information for Test Laboratories:
For detailed information on the EN comparis wing address: “nk_cuon test and other tests, contact the follo stomer@whirlpool.com”.
