5019 496 90464
GB
Quick Reference Guide
Before using the dishwasher, read the user instructions!
BK/I/B/GB
(We reserve the right to make technical modifications)
GSIP 6627
Time and failure display
Indicates in hours the time remaining until the start of
the wash cycle. Switches off at programme start and
indicates the remaining time in hours and minutes.
“F....” Information for the After-Sales Service
“Delayed start” button
The wash cycle can be programmed to start after 1 - 24
hours. With each successive touch of the button, the
delayed start indicator increases by 1 hour, and after 24
returns to 00. Then press the Start button. The
dishwasher will start at the set time.
“Half load - Multizone” button
Load the upper or lower rack only.
This function can be used with any programme.
Press once = upper rack (the indication lamp/symbol comes on)
Press twice = lower rack (the indication lamp/symbol comes on)
Press 3 times = Off (half load function deactivated).
When washing without the top rack, press the “Half
Load” button twice, or “Lower rack wash” (the
corresponding LED/symbol comes on).
Antibacterial rinse 4) 5)
This function adds an antibacterial rinse at the end of the
wash cycle, thereby guaranteeing a perfectly clean and
sanitized load. The lamp will light up when the function
is activated. If the temperature is not maintained during
the antibacterial cycle (e.g. if the door is opened and
remains open for a long time), the lamp will start blinking
to indicate that sanitation is not guaranteed.
1) Reference programme for energy label EN 50242;
2) Refer to “User instructions”;
3) Programme data obtained in conformity with European
standard EN 50242. Values may vary in relation to usage, e.g.:
different loads, options, water temperatures - above or below
15°C - as well as water hardness and power supply voltage, etc.
4) The bacteria removal efficiency has been tested by the Institut
Pasteur de Lille (France), based on the NF EN 13697 standard
of November 2001.
5) These programmes can be used with the Antibacterial rinse option.
6) Energy saving programme with prolonged drying cycle.
Programme selection button
On / Off button
Start button
Switches “on” when the dishwasher is operating.
Flashes when a fault occurs. Switches off at the
end of the programme.
Options 3)
Programme chart Detergent 2) Consumption 3)
Programmes Loading instructions A B Litres kWh Minutes
Pre-Rinse cold Crockery to be washed later. - - 4.0 0.03 14
Glass 40°C Light soiling, for example glasses and cups. X - 10.0 0.85 100
Rapid 30 min 40°C Lightly soiled crockery with no dried-on food. X - 10.0 0.65 30
Bio 1) 5) 6) 50°C Normally soiled crockery. X X 13.0 1.05 195
Standard 5) 60°C Normally or heavily soiled crockery. X X 13.0 1.25 120
Intensive 5) 70°C Recommended programme for heavily soiled
crockery, especially suitable for pans and
saucepans.
X X 14.0 1.55 155
Important information for Test Laboratories:
For detailed information on the EN comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.
