Compact Binoculars
Congratulations on selecting your new Carson Binocular! In order to achieve
optimum performance, please follow instructions for proper use and care.
EYE ADJUSTMENTS: HOW TO ADJUST FOR DISTANCE BETWEEN THE EYES
The distance between the eyes, interpupillary distance,
varies from person to person. To achieve perfect alignment
of lens to eye:
1. Hold binoculars in normal viewing position.
2. Rotate barrels closer or farther apart until you see
a single circular eld.
INDIVIDUALLY ESTABLISHING LEFT/RIGHT EYE FOCUS:
Most binoculars have a center focus knob and an independent right diopter eyepiece to account for small
dierences in the strength of each eye. Please follow the steps below to focus properly:
1. Eyecups should be fully extended if you don’t wear glasses. If you wear glasses, twist/roll down
eyecups to bring your eyes closer to the binocular lens.
2. With right eye closed, rotate the central focusing knob until the image in the left eyepiece is sharp.
3. With left eye closed, rotate the independent right diopter eyepiece until the image is sharp.
4. Image should now be focused to your individual eye strength and will retain setting for future use.
Note: If you still cannot focus, rotate adjustable right diopter to reset by lining up symbols (triangle, line, circle,
etc.) on diopter eyepiece and barrel. Then repeat Focusing Steps 2 and 3.
FOCUSING YOUR BINOCULARS:
While viewing an image, adjust the center focus wheel for distance.
1
Rozwiązywanie problemów Carson JD-822
Jeśli dokładnie przeczytałeś instrukcję, ale nie znalazłeś rozwiązania swojego problemu, poproś o pomoc innych użytkowników
Specyfikacje
| Kolor produktu: | Black, Grey |
| Waga produktu: | 170 g |
| Wymiary produktu (SxGxW): | 102 x 86 x 29 mm |
| Walizka: | Tak |
| Powiekszenie: | 8 x |
| Wsparcie oczu: | 10 mm |
| Średnica obiektywna: | 22 mm |
| Rodzaj pryzmatu: | BK-7 |
