Hager Ltd. Hortonwood 50, Hortonwood, Telford, TF1 7FT / 01952 675 675 1
Invicta 3 TP&N Distribution Board
125A
Invicta 3 125A
TP&N Distribution Boards
A range of Type B TPN Distribution boards
with high aesthetics ideal for commercial
ofces, healthcare and education projects
where the boards may be sited in public areas.
Features & Benefits
- High aesthetic glazed door option for siting in public areas
- Range of incomer options suitable for a wide range of building
applications
- Door locking kit with key for additional security
- Meter and surge protection options to meet application needs.
- Part of a wider range of Distribution boards
- Comprehensive solution for commercial building applications including
250A, Power & Lighting boards and Hybrid Distribution board
Description
Cat ref.
Plain door
Cat ref.
Glazed door
Cat ref.
Residential
Applications
4 Triple Pole Ways 125A TP&N Board JK104B ¹ JK104BG ¹ JK104BA3 ²
6 Triple Pole Ways 125A TP&N Board JK106B ¹ JK106BG ¹ JK106BA3 ²
8 Triple Pole Ways 125A TP&N Board JK108B ¹ JK108BG ¹ JK108BA3 ²
12 Triple Pole Ways 125A TP&N Board JK112B JK112BG JK112BA3 ²
16 Triple Pole Ways 125A TP&N Board JK116B JK116BG JK116BA3 ²
18 Triple Pole Ways 125A TP&N Board JK118B JK118BG JK118BA3 ²
24 Triple Pole Ways 125A TP&N Board JK124B JK124BG JK124BA3 ²
Incomer Kits for 125A Boards Cat Ref.
3 Pole 100A Switch Disconnector Incomer Kit (Fits within distribution board) JK11003S
4 Pole 100A Switch Disconnector Incomer Kit (Fits within distribution board) JK11004S
3 Pole 125A Switch Disconnector Incomer Kit (Fits within distribution board) JK11253S
4 Pole 125A Switch Disconnector Incomer Kit (Fits within distribution board) JK11254S
4 Pole 63A Contactor Incomer Kit includes Switch Disconnector (ts below distribution board, 300mm high) JK10634C
4 Pole 100A Contactor Incomer Kit includes Switch Disconnector (ts below distribution board, 450mm high) JK11004C
125A Direct Connection Kit (Fits within distribution board) JK11254D
4 Pole 63A 30mA RCCB Incomer Kit (Fits within distribution board) JK10634RH
4 Pole 100A 30mA RCCB Incomer Kit (Fits within distribution board) JK11004RH
4 Pole 100A 300mA RCCB Incomer Kit (Fits within distribution board) JK11004RL
4 Pole 100A 300mA Time Delayed RCCB Incomer Kit (Fits within distribution board) JK11004RLD
4 Pole 100A 100mA RCCB Incomer Kit (Fits within distribution board) JK11004RM
4 Pole 100A 100mA Time Delayed RCCB Incomer Kit (Fits within distribution board) JK11004RMD
125A 4 pole Changeover Incomer Kit (Fits within distribution board) JK11254CO
Conforming the BS EN 61439-3, the Invicta boards are available with
glazed or solid steel doors to suit installation requirements. A wide range
of incoming options create a versatile solution. Metering and surge
protection options ensure efcient integration in to the buildings electrical
supply model. A 250A TP&N board range is also available for higher load
applications.
Rozwiązywanie problemów Hager JK106B
Jeśli dokładnie przeczytałeś instrukcję, ale nie znalazłeś rozwiązania swojego problemu, poproś o pomoc innych użytkowników
Specyfikacje
| Kolor produktu: | Szary |
| Wysokość produktu: | 550 mm |
| Szerokość produktu: | 465 mm |
| Głębokość produktu: | 132.5 mm |
| Stopień ochrony IP: | IP30 |
