Mikrotik CRS310-8G+2S+IN Instrukcja
Oto Mikrotik CRS310-8G+2S+IN (przełącznik) instrukcja użytkownika. 19 strony w języku Polski o wadze 1.2 Mb. Jeśli nie możesz znaleźć odpowiedzi na swoje pytanie Zapytaj naszą społeczność.
Strona 1/19
EN - English -Quick Guide
EN - English -Quick Guide
EN - English -Quick Guide
EN - English -Quick GuideEN - English -Quick Guide:
This Quick Guide covers the model: CRS310-8G+2S+IN.
This is a network device. You can find the product model name on the case label (ID).
Please visit the user manual page on for the full, latest user manual. Or scan the QR code with your mobile phone.
https://mt.lv/um
The most relevant technical specifications for this product can be found on the last page of this Quick Guide.
Technical specifications, Full EU Declaration of Conformity, brochures, and more info about products at
https://mikrotik.com/products
Configuration manual for software in your language with additional information can be found athttps://mt.lv/help
MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants
First steps:
First steps:
First steps:
First steps:First steps:
Connect with your computer to the device;
Download the configuration tool ;
https://mt.lv/winbox
Open the tab and connect to the device using the MAC address;
Neighbors
The user name: , by default there is no password
admin
(or, for some models, check user and wireless passwords on the sticker);
(or, for some models, check user and wireless passwords on the sticker);
(or, for some models, check user and wireless passwords on the sticker);
(or, for some models, check user and wireless passwords on the sticker);(or, for some models, check user and wireless passwords on the sticker);
To dupdate the device to the latest software version ownload the latest RouterOS software from ;
https://mikrotik.com/download
Choose ARM packages, and save them to your computer;
Return to the WinBox and upload downloaded packages;
Restart the device.
Safety Information:
Safety Information:
Safety Information:
Safety Information:Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
The socket-outlet shall be installed near the equipment and shall be easily accessible.
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
To avoid contamination of the environment, separate the device from household waste and dispose of it in a safe manner, for example, in designated areas.
Become familiar with procedures for properly transporting the equipment to designated collection points in your area.
Manufacturer: Mikrotikls SIA, Unijas 2, Riga, Latvia, LV1039.
This device needs to be upgraded to RouterOS v7.10 or the latest software version to ensure compliance with local authority regulations!
It is the end user's responsibility to follow local country regulations. All MikroTik devices must be professionally installed.
Rozwiązywanie problemów Mikrotik CRS310-8G+2S+IN
Jeśli dokładnie przeczytałeś instrukcję, ale nie znalazłeś rozwiązania swojego problemu, poproś o pomoc innych użytkowników
Specyfikacje
| Kolor produktu: | Biały |
| Źródło zasilania: | DC |
| Wysokość produktu: | 44 mm |
| Szerokość produktu: | 200 mm |
| Głębokość produktu: | 206.1 mm |
| Certyfikaty: | CE, EAC, ROHS |
| Maksymalne zużycie mocy: | 34 W |
| Wielkość pamięci flash: | 32 MB |
| Pojemność pamięci wewnętrznej: | 256 MB |
| Procesor wbudowany: | Tak |
| Obsługa PoE: | Tak |
| Zakres temperatur (eksploatacja): | -40 - 60 °C |
| Układ: | 1U |
| Taktowanie procesora: | 800 MHz |
| Model procesora: | 98DX226S |
| Liczba wentylatorów: | 1 went. |
| Zainstalowany system operacyjny: | RouterOS |
| Stopień ochrony IP: | IP20 |
| Możliwości montowania w stelażu: | Tak |
| Typ przełącznika: | Zarządzany |
| Podstawowe przełączanie RJ-45 Liczba portów Ethernet: | 8 |
| Podstawowe przełączania Ethernet RJ-45 porty typ: | 2.5G Ethernet (100/1000/2500) |
| Obsługa 10G: | Tak |
| Wielkość tabeli adresów: | - wejścia |
| Przepustowość rutowania/przełączania: | - Gbit/s |
| Przełącznik wielowarstwowy: | L3 |
| Zasilacz dołączony: | Tak |
| Napięcie wejściowe DC: | 18 - 57 V |
| MTBF (Średni okres międzyawaryjny): | 200000 h |
| Ilość slotów Modułu SFP+: | 2 |
| Ilość portów USB typu A: | 1 |
