Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: March 14, 2024
Product ID
M2-HDD-DUPLICATOR-N1
Top
Rear
1 to 1 M.2 NVMe Drive Duplicator Dock
Component Function
1Target Drive Bay • Insert the to Copy toTarget M.2 NVMe Drive
2Source Drive Bay Insert the to Copy from• Source M.2 NVMe Drive
3Mode Selector Switch • Press and Hold to change between or PC
Duplicator Mode
4Mode LED Indicators • Solid Green: PC Mode
• Solid Blue: Duplicator Mode
5Progress LED Indicators • Indicates progress from during the 25% to 100%
Duplication process
6Drive LEDs
• Solid Blue: M.2 Drive Indicates the is detected
• Flashing Red: M.2 There is an error reading the
Drive M.2 Drive or the was removed during
duplication
• Solid Purple: Target M.2 DriveIndicates the is
too small to duplicate to
7Start Button • Starts the processDrive Duplication
• See section for more informationOperation
8USB-C Host Connection
• Connect the to an Drive Duplicator Dock
available on a USB-C Port Host Computer
• Only required for PC Mode
9DC Power Input Connect the included • Universal Power Adapter
10 Power Switch Turn the or • M.2 Drive Duplicator Dock On O
Requirements
For the latest product information, technical specications, and declarations of
conformance, please visit: www.StarTech.com/M2-HDD-DUPLICATOR-N1
Package Contents
• M.2 Drive Duplicator Dock x 1
• 3ft (1m) USB-C to USB-C Cable x 1
• 3ft (1m) USB-A to USB-C Cable x 1
• Universal Power Adapter (NA/UE/UK/ANZ) x 1
• Quick-Start Guide x 1
1
2
3 4 65 7
8 9 10
