Thank you for purchasing a StarTech.com PCIVGAV7 PCI VGA Video Card. This
convenient video card is fully compliant with PCI 2.2 and provides high quality 2D
display at resolutions of up to 1600 x 1200 pixels.
Compliant with PCI 2.2 (33/66 MHz) •
Maximum 2D Resolution for 32-bit (1280x1024 @60Hz) and 16-bit (1600x1200 •
@ 75Hz)
Maximum color depth up to 16.7M colors output •
1 X Driver CD •
1 X Instruction Manual •
1 X Video Card •
D-Sub RGB (VGA) Connector1.
PCI Interface2.
1 2
Make sure that your system is unplugged and you are grounded.1.
Remove the cover of your system (see your computer’s user manual for details, 2.
if necessary) and gently turn your computer onto its side, so that the PCI
expansion slot openings on the motherboard are facing upwards.
Locate an empty PCI slot (usually white in color) and remove the metal plate 3.
that covers the corresponding rear bracket.You may need a Phillips screwdriver
to perform this step. Retain the screw! You will need it to secure the card later.
Gently insert the card into the empty slot, making sure it is firmly seated.4.
Secure the card in place using the screw you removed in Step 3, as applicable.5.
Replace and secure the computer cover. 6.
Open the 1. file located in the following path: X:\Windows 2000_XP\ Setup.exe
setup.exe, where X: designates the CD/DVD-ROM drive.
When the InstallShield welcome screen appears, click2. . If you receive a Next
notification that the software has not passed Windows Logo testing, click
Continue Anyway to proceed with the installation.
Once all files have been installed, select 3. Yes, I want to restart my computer
now, and click to restart your computer and complete the installation Finish
process. If you wish to verify the installation, open the Device Manager and
check that the drivers have been recognized.
Once the computer has successfully rebooted, your new VGA port is ready for 4.
use.
Specification PCIVGAV7
Interface PCI 2.2 33/66MHz
Chipset XGI Volari™ Z7
Memory 16MByte DDR RAM
Port Type D-Sub RGB (VGA) Connector
Power Consumption 1.4W
OS Support Windows XP/2000/Vista™; Linux
Environment
Operating Temperature: -10 C ~ 85 C
Storage Temperature: -20 C ~ 90 C
Operating Humidity: 5 ~ 95% RH
Rozwiązywanie problemów StarTech.com PCIVGAV7
Jeśli dokładnie przeczytałeś instrukcję, ale nie znalazłeś rozwiązania swojego problemu, poproś o pomoc innych użytkowników
Specyfikacje
| Wysokość produktu: | 19 mm |
| Szerokość produktu: | 160 mm |
| Głębokość produktu: | 120 mm |
| Waga produktu: | 66 g |
| Szerokość opakowania: | 34 mm |
| Wysokość opakowania: | 154 mm |
| Głębokość opakowania: | 220 mm |
| Zgodny z Mac: | Nie |
| Typ interfejsu: | PCI |
| Zakres temperatur (eksploatacja): | -10 - 85 °C |
| Zakres wilgotności względnej: | 5 - 95 % |
| Pobór mocy: | 1.4 W |
| Waga wraz z opakowaniem: | 170 g |
| Rodzaj chłodzenia: | Pasywne |
| Maks. rozdzielczość: | 1600 x 1200 px |
| Wersja DirectX: | Nie |
| Liczba portów VGA (D-Sub): | 1 |
| System operacyjny: | Windows XP/2000/Vista/Server 2000/2003, \nLinux Kernel 2.4.18 - 2.4.22, 2.6 +, \nFreeBSD, \nSolaris, \nNetWare, \nDOS |
| Procesor graficzny: | XGI Z7 |
| Typ pamięci adaptera grafiki: | GDDR |
| Magistrala pamięci: | 32 bit |
| Minimalna moc zasilacza: | - W |
